1.Stable performance
2.Reasonable structure
3.Low noise
4.It is suitable for different operation requirement.
| Model | SF244/SF324 | |
| Type | Wheel type 4×4 | |
| Engine Model | SF138-2/SF188-2 | |
| Engine Type | Single Cylinder,Horizontal,Four-stroke,Directly Inject | |
| Bore×Stroke(mm) | 122×118/135×130 | |
| Rated Speed(r/min) | 2200 | |
| Rated Power(kW) | 17.6/23.8 | |
| Cooling Method | Forced water cooling | |
| Rated Traction(N) | 4700/5600 | |
| Main Dimension of Tractor(mm) | Overall Dimension(mm) | 2990X1580X1400 |
| Wheelbase(mm) | 1550(tread960)/1585(tread1200,1300) | |
| Front Tread(mm) | 1020(tread960) / 1160(tread1200) / 1260(tread1300) | |
| Rear Tread(mm) | 1025(tread960) / 1195 (tread1200) / 1295(tread1300) | |
| MIN Groud Clearance(mm) | 210(tread960)/230(tread1200,1300) | |
| Turning Radius(mm) | 4900±200 | |
| Tractor Weight (kg) | Structral Weight | 1120/1180 |
| Usage Weight | 1320/1380 | |
| Theoretical Speed (km/h) Transmission(4+1)×2 | Front/Rear Tyres | 6.00-16/9.5-24 |
| ForwardⅠ-Ⅷ | 3.03-4.98-7.12-8.5-11.12-13.97-19.97-31.19 | |
| Revise Ⅰ-Ⅱ | 4.01-11.25 | |
| LOAD QTY IN 40HQ(IN SKD) | 16UNITS | |
| FOB QINGDAO PRICE | 2550$/2700$ | |
