1.Easy to start: the engine is easy to start, providing sufficient power under the worst conditions;
2.Wear resistance: unique graphite ceramic seal design, equipped with cast iron volute, wear resistance, long life;
3.Strong protection body: frame frame protection, easy to handle and provide effective protection for the whole machine.
| Model | WG20 | WG30 |
| Product Description | Gasoline Water Pump | |
| Pump | ||
| Pump type | Centrifugal Pump | |
| Flow(m³/H) | 35 | 55 |
| Suction Port Diameter(mm/inch) | 50/2 | 80/3 |
| Discharge Port Diameter(mm/inch) | 50/2 | 80/3 |
| Total Head Lift(m) | 30 | 30 |
| Suction Head Lift(m) | 7 | 7 |
| Engine | ||
| Model | GB200 | GB200 |
| Engine Type | OHV, Air Cooling, 4 Stroke, | |
| Displacement (cc) | 196 | 196 |
| Max Power Output(W) | 4500 | 4500 |
| Starting System | Recoil | Recoil |
| Engine Oil Capacity (ml) | 600 | 600 |
| Recommended Oil | SAE 10W-30 | SAE 10W-30 |
| Fuel Tank Size (L ) | 2.6 | 2.6 |
| Accessories | Spark plug Socket, Clamp*3, Filter, Pipe joint*2, Joint*2, Gasket*2 | Spark plug Socket, Clamp*3, Filter, Pipe joint*2, Joint*2, Gasket*2 |
| Packing Details | ||
| Outside Packing Dimensions (mm) (L x W x H) | 515×415×415 | 530×415×445 |
| Net Wieght (kg) | 24 | 26 |
| 20’GP Container Qty 20FT | 305 | 305 |
| 40’GP Container Qty 40GP | 625 | 615 |
| 40’HQ Container Qty 40HQ | 750 | 615 |
| Certification | CE,EC,EPA,CARB | CE,EC,EPA,CARB |
